Crossroads Wind Power, LLC Crossroads Wind Farm

Farnsworth Group is providing surveying, transportation engineering, site design, and permitting services for the 60 MW Crossroads Wind Project consisting of 24 turbines and 4 miles of external transmission lines.
Design services will include 7 miles of County and Township Roadway improvements.
Transportation and site services for the Crossroads Wind Project includes:

Base map development
Assisted with road use agreement development
Transportation plan development
County and township highway evaluations (including drainage)
Pre-construction public roadway condition survey
Traffic Impact Analysis (TIA) report
State highway, county highway, and township roadway permit applications
Railroad permit applications
Coordination with railroad related to crossing improvements
Utility relocation coordination
Coordination meetings with road authorities
Project meetings
County highway and township roadway intersection improvement plans
Township roadway improvement plans – strengthening and widening including drainage
Private access road design including drainage
Turbine site designs
Lay down yard design and grading plans
2D hydraulic site analysis
Site, private and public roadway bill of quantities
Site, private and public roadway technical specifications
Spill prevention, control and countermeasures plan (SPCC)
Limited construction administration and support

Marathon Petroleum, LP Commissioning of a Pipeline to Transport Natural Gas Liquids

Farnsworth Group assisted with the development of commissioning and hydrostatic test plans for the Utica Build-Out projects. The goal of these projects was to transport Utica natural gas liquids (NGL). Some of the projects included:

Expansion of three existing pipeline systems
A major facility expansion
Three minor facility expansions
Installation of a new 49-mile long 12-IN pipeline from Harpster, Ohio to Lima, Ohio.

Farnsworth Group teamed with the client during conceptual engineering of the project to begin developing high-level facility and mainline fill plans. These plans included first-operations plans for several new mainline pump units, provers, meters, control valves, sumps, DRA skids, and new large floating roof storage tanks. In total, 13 commissioning plans and a hydrostatic test plan were developed. We also assisted with the field engineering of the commissioning and hydrostatic test work – acting as liaison between project contractors and the client. Once the commissioning was completed, the movement of additional barrels began to flow across the expanded system.
